Mechanical Stretching Machine
MS Serial
Description: Various printing frame sizes can be handled by the MS Mechanical Stretching Machine. Single or multiple printing frames is able to be processed without any additional platform. Each clamp is smoothly sliding on its respective rail for producing the high tension screen with even stretching force on the entire screen. User-friendly and easy operation is the key feature of the MS machine.
1.         The longitudinal and transversal directions are stretched independently with one regulator on each side.
2.         The screen is held firmly by the sliding clamps which running on the precision double rails and ball bearings. This design makes the stretching more steady.
3.         The machine is equipped with one set of cylinders (4 pcs at four corners).After finish stretching action, the frame will be raised to the screen by the cylinders to ensure the proper contact.
4.         The size of the MS machine is manufactured against the customers’ requirement

PARAMETER


Model
MS-1015
MS-1215
MS-1218
Max. stretching area
1000×1500 mm
1200×1500mm
1200×1800mm
Min. stretching area
400×400mm
400×400mm
400×400mm
Max. stretching force
45N/cm
45N/cm
45N/cm
Manifold air pressure
0.50.6Mpa
0.50.6Mpa
0.50.6Mpa
Dimension(mm)
2020×1670×900
2350×1940×900
2600×1860×900
Net weight(approx.)
190 kg
200 kg
250kg
