Description: Various printing frame sizes can be handled by the Automatic Mechanical Stretching Machine. Single or multiple printing frames is able to be processed without any additional platform. Various types of fabric can be used. Each clamp is smoothly sliding on its respective rail for producing the high tension screen with uniform stretching force on the entire screen. User-friendly and easy operation is the key feature of the AMS machine.
1. The machine is equipped with two operation mode: manual mode and automatic mode. The operator can choose the operation mode according to the stretching requirement.
2. All the machine adjustment can be carried out with the integrated control panel or the unique remote control console.
3. The longitudinal and transversal directions are stretched independently with independent motors.
4. The stretching speed is controlled by the “Panasonic” frequency inverter. There are two stretching speed: the fast speed and the slow speed. The fast speed can set up the screen in a short time. While the slow speed can stretch the screen in a fine situation ,achieving the most accurate stretching requirement.
5. The screen is held firmly by the sliding clamps which running on the precision double rails and ball bearings. This design make the stretching more steady.
6. This machine is particularly suitable for stretching multiple screens at one time or stretching the ultra large screen frame format.
7. After finish stretching, the screen frame will be pressed onto the mesh mechanically to ensure the proper contact for next process
8. The fabric pressing bars is available if specifically requested by client.
PARAMETER
Model
|
AMS-3350
|
AMS-3075
|
Max. stretching area
|
3300×5000mm
|
3000mm×7500mm
|
Min. stretching area
|
600×600mm
|
600×600mm
|
Power
|
2.45KW
|
2.45KW
|
Dimension(mm)
|
7250×4700×1700
|
9800×4400×1700
|
Net weight(approx.)
|
2191kg
|
2616 kg
|
Max. stretching force
|
45N/cm
|
45N/cm
|
|
